Infinium QRS-12 Digital Touch-Screen 12-Lead ECG Machine

The Infinium Digital Touch-Screen 12-Lead ECG Machine with keyboard is designed for a fast paced work environment. Features and Benefits Smart and portable design 9-inch high resolution TFT touch screen with adjustable angle, easy to view Waterproof and full alphanumeric keyboard with shortcut keys Broad frequency response 0.05~250Hz for weaker signal recognition and capture, more suitable for pediatrics Specific age and gender differential validity in CardioPro analysis program maximizes the accuracy of the ECG interpretation Unique ECG acquisition module with 3 independent keys streamlines the whole workflow ECG electrode placement diagram for lead connection guide and alarm Up to 300 seconds frozen waveforms reviewable and recordable Up to 300 seconds R-R analysis in 1 or 3 rhythms for easier in arrhythmia locating Cabrera mode available Support various file formats: XML, DICOM, JPG and PDF Local storage for up to 1500 files 3 ways file storage: local memory, SD card, USB flash disk ECG management software by LAN or WIFI connection Materials Included QRS-12 ECG Machine (1) 12-Lead ECG Cable (4) Limb Electrodes (6) Chest Electrodes (1) ECG Z-Fold Pack of Paper (1) Lithium Ion Battery (1) Power Cord User Manual Technical Specifications Signal Processing Specification ECG Interpretation: CardioPro ECG analysis program for adults and pediatrics Acquisition Mode: Simultaneous standard 12-lead in pre-acquisition or post-acquisition A/D Conversion: 24 bit Sampling Rate: 8,000 samples/second/channel Frequency Response: 0.05 Hz~250 Hz Common Mode Rejection Ratio: >105dB</li> <li><strong>Polarization Voltage: </strong>±550mV</li> <li><strong>Input Circuit:</strong> Floating circuit input</li> <li><strong>Input Impedance:</strong> ≥50 MΩ</li> <li><strong>Input CIR Current:</strong> ≤0.1 μA</li> <li><strong>Patient Leakage Current: </strong><10 μA105dB Polarization Voltage: ±550mV Input Circuit: Floating circuit input Input Impedance: ≥50 MΩ Input CIR Current: ≤0.1 μA Patient Leakage Current:  Time Constant: ≥3.2 s Noise Level:  Sensitivity Threshold: ≤20 μVp-p Calibration Voltage: 1 mV±5 % Sensitivity: Eight levels as ( 1.25, 2.5, 5, 10, 20, 10/5, 20/10) mm/mV, Auto Gain Filter: Setting EMG filter: 25/35/75/100/150/250Hz Baseline wander filter: 0.01/0.02/0.05/0.35/0.5/0.8Hz AC Filter: 50Hz, 60Hz Heart Rate Range: 30~300 bpm Acquisition Time: 10~24 seconds Display and Keyboard Specifications Display Type: 8.9 inch TFT LCD with touch screen Display Resolution: 1280 × 768 Display Data: Waveforms, heart rate, lead connection, clock, record mode, filters, sensitivity, paper speed, patient ID,name, gender, age, system prompt, alarming messages, battery, power indicator, SD card label Waveform Display Mode: Same screen display: 3*4, 3*4 1R, 6*2, 6*2 1R, 12*1 Split-screen display: 3*4, 6*2 Keyboard Type: Waterproof material, integrated full alphanumeric keyboard with quick-access function keys Recorder Specifications: Recorder Technology: Thermal dot matrix word printing system Recorder Resolution: 8 points/mm (perpendicular) 40 points/mm (horizontal, 25 mm/s) Recorder Speed: (5, 6.25, 10, 12.5, 25, 50) mm/s±5% Recording Paper: Z-Fold Paper 210 mm x 150 mm; 140 sheets Standard Soft Specifications: Measurement and Interpretation: Supports measurement and interpretation with CardioPro ECG analysis program for adults and pediatrics Measurement Values: HR, PR interval, QRS duration, QT/QTC interval, P/QRS/T axis, RV5/SV1 voltage, RV5 SV1 voltage Minnesota Code: With Minnesota code Working Mode: Automatic mode, Manual mode, Rhythm mode, Trigger mode, Economic mode, Cycle mode, Upload mode DEMO Mode: Normal ECG, Arrhythmia ECG QTC Formula: Bazett, Fridercia, Framingham, Hodges Rhythm Analysis: Single Rhythm Mode: 30-300 seconds Three Rhythms Mode: 30-100 seconds for each lead Auto-Trigger Mode: Auto-trigger printing when arrhythmia is detected during the examination Extended Printing in Arrhythmia: Supports extended arrhythmia waveform printing in automatic mode Waveform Frozen: Supports 300 seconds of waveform frozen Pacemaker Detection: Weak, Normal, Enhance Report Auto-Saved: Selectable auto-saved file Interpretation Printout: Selectable interpretation printing Report Preview: Preview the report before printing Data Format: JPEG, XML, DICOM, PDF, ECG. Alarming System: Voice and visual alarming for: Lead off, No paper, Low battery Patient Information Setting: Record No., Name, Gender, D.O.B, Height, Weight, BP, Race, Pacemaker, Medication, Accession No., Ref-physician, Technician, Physician, Room No., User-define Language: English, Russian, Spanish, French, Italian, Polish, Czech, German, Portuguese, Ukrainian, Turkish Local Memory Capacity: More than 3000 files Report Specifications: Report Type: Manual report, Simple report, Detail report, MVB report (Median beat report) Record Format: 3*4, 3*4 1R, 3*4 3R; 6*2, 6*2 1R, 6*2 3R; 12*1, 12*1 1R External Peripheral Use: Patient Cable Socket: Connect to the patient cable SD Card Port: 8 GB SD card for data transfer Two USB Ports: Support USB flash disk and barcode scanner LAN Port: Communication with ECG-1000 workstation software on PC VGA Port: Connect to external monitor Power Supply Power Supply: AC/DC AC/DC: Power supply 100 V~240 V, 50 Hz /60 Hz, 110 VA Battery Power Supply: Rechargeable lithium battery, 14.8 V，4400 mAh Battery Capacity: Support more than 3.0 hours for continuous operation Battery Charge: Time Approximately 4 hours for total charge Physical Characteristics Dimensions: 345 mm x 260 mm 128.5 mm Weight: 7.5 lbs Environmental Requirements Transportation Environment Temperature: -20ºC ~ 55ºC Relative Humidity: ≤95% (No condensation) Air Pressure: 70 kPa~106 kPa Storage Environment Temperature: -20ºC ~ 55ºC Relative Humidity: ≤ 95% (No condensation) Air Pressure: 70 kPa~106 kPa Using Environment Temperature:  5ºC ~ 40ºC Relative Humidity: ≤95% (No condensation) Air Pressure: 86 kPa~106 kPa
